Zebra Xilll Series
Ribbon LED - Automatically set during
calibrate.
Mark LED - Automatically set during
calibrate.
LCD Adjust- Adj. display brightness.
Resolution - Full*, Half.
Firmware - Firmware version & part number
printed.
Language - Sets the display language.
English*, Spanish, French, German, Italian,
Norwegian, Portuguese, Swedish, Danish,
Spanish2, Dutch, Finnish, Custom.
Save Settings -
Permanent* - Saves changes even after
power is turned off.
Temporary - Saves until changed again or
until power is turned off.
Cancel - Cancels all changes since entering
Config mode.
Load defaults - Loads Factory defaults.
N/A
N/A
N/A
N/A
N/A
Format Convert – (None*, 150-300, 150-
600, 200-600, 300-600).
Selects the bitmap scaling factor.
Idle Display (opt)- (Firmware ver, mm/dd/yy
(24 hr), dd/mm/yy (24 hr), mm/dd/yy (12 hr),
dd/mm/yy (12). Sets LCD display options for
real time clock, if installed.
Table 32: PPI1 Menu (continued)
Automatically set during Auto Calibrate.
Automatically set during Auto Calibrate
N/A
IGP/PPI1 SETUP Menu,
Resolution Mode - Full*, Half
DIAGNOSTIC Menu,
Software Build & Config printout
PRINTER CONTROL Menu, Display Language -
English*, Spanish, French, German, Italian, Portuguese.
CONFIG CONTROL Menu,
Save Config. - Saves changes to 8 cust. Configs. (same
as Zebra Permanent).
NOTE: Changes to all configs. act same as Zebra
Temporary mode unless config. saved as 1 of 8 custom
Configs.
Cancel N/A - Printer auto cancels like Zebra if Config
changes are not saved or if another Config is loaded.
Load Config. - Loads Factory default and 1-8 custom
configurations.
Power-Up Config - Selects Factory or 1 of 8 custom
Configs. as power-up configuration.
Delete Config. - Deletes any of up to 8 saved custom
configurations.
Print Config. - Prints Factory, Pwr-Up, Current, All, or
custom Configs. 1-8.
Protect Configs. - When enabled, prevents saving &
overwriting any existing saved custom Config.
Name Config. 1-8 - Permits using up to 15 characters to
name a custom Config.
IGP/PPI1 SETUP Menu,
Resolution Mode - Full*, Half
N/A
T5000e with PPI1 Emulation
