User-Defined St2 (Start Code 2)
(From page 159, page 161, page 164, page 165, page 171, page 173.) This
option allows you to define your own value (in ASCII characters) for the User
Defined option in the Lead-in Chars menu. "St2" specifies Start Code 2. See
"Lead-in Chars" on page 226 for additional information.
The range is 40 - FF, and the factory default is 5F.
User-Defined Stp (Stop Code)
(From page 159, page 161, page 164, page 165, page 171, page 173.) This
option allows you to define your own value (in ASCII characters) for the User
Defined option in the Lead-in Chars menu. "Stp" specifies Stop Code. See
"Lead-in Chars" on page 226 for additional information.
The range is 40 - FF, and the factory default is 5B.
Var Form Adjust
(From page 175.) This specifies an amount (in tenths of inches) to add to the
length of variable-length forms. Variable-length forms use a semicolon at the
end of the CREATE command: ~CREATE;<FORMNAME>;0.
Typically, variable-length forms are determined by the elements within the
form. The longest form element becomes the overall form length. This option
allows an additional space to be added to the form length.
The range is 00.0 to 03.0 inches, and the factory default is 00.0 inches.
Var Form Type
(From page 175.)
•
Add Nothing. When selected, no action is taken.
•
Add ;0. When selected, the form length ends at the longest printed
∼
element. (Same as
•
Add ;X. When selected, the form length is the same as the physical page
length (the Label Length menu under MEDIA CONTROL). (Same as
∼
CREATE;filename;X)
The factory default is Add Nothing.
Vert. DPI Adjust
(From page 183.) This option fine adjusts the resolution used to convert the
coordinates of page elements (barcodes, font fields, graphic images, lines
and boxes). The coordinates received from the host are in 1/10 mm and are
converted to engine resolution (203 or 300 dpi). In cases where the printed
image length is incorrect, the vertical resolution value PPI2 uses for
calculations can be fine adjusted between –100 and +100. Negative values
result in a lower DPI value and thus a longer image. Positive values result in a
higher DPI value and thus a shorter image. Note that this adjustment does not
affect the size of fonts and barcodes, only the coordinates.
The factory default is 0.
CREATE;filename;0)
