Appendix F
Zebra Xilll Series
Label Top - (-120 to +120 dot rows) +00*.
Adjusts vertical print position on label.
Left Position - (-9999 to +9999)
0000*. Adjusts image horizontally from left
edge of label in dots.
(+) shifts image left. (-) shifts to right.
Head Test Count- (0000*-9999) 0000
disables test.
Head Resistor - Must be updated when
printhead changed.
Verifier Port - How printer reacts to Optional
On-Line Verifier.
Off* - Verifier port is off.
1 VER-RPRINT - Label reprinted if error
detected.
2 VER-THRUPUT - Allows greatest
throughput but may not indicate verification
error immediately.
Applicator Port
Web S. - Auto set during calibrate.
Media S. Auto set during calibrate.
Ribbon S. - Auto set during calibrate.
Mark S. - Auto set during calibrate.
Mark Med S. - Auto set during calibrate.
Media LED - Automatically set during
calibrate.
368
Table 32: PPI1 Menu (continued)
T5000e with PPI1 Emulation
QUICK SETUP Menu,
Ver Image Shift - (-1 to+12.8") 0.0*". Adjusts vertical print
position on label.
Or
IGP/PPI1 SETUP Menu,
Top Position - (-100 to +100 dots/inch)
0 dots/inch*. Adj vert. position in dot/in.
NOTE: Only avail. in later version SW.
QUICK SETUP Menu,
Hor Image Shift - (-1.0 to +1.0) 0.0"*.
Adjusts image horizontally from left edge of label in
inches.
(+) shifts image left. (-) shifts image right.
Or
IGP/PPI1 SETUP Menu,
Left Position - (-1000 to +1000 dots) 0 dots*. Adjusts
image horiz. in dots.
NOTE: Only avail. in later version SW.
DIAGNOSTIC Menu,
Ptr Media Dist - Inches*, MM.
NOTE: Head Resistance detected & updated
automatically by SW.
Off - Default if no validator installed.
VALIDATOR Menu (Opt),
Validator Funct. - Enable*, Disable. Automatically
Enabled when opt installed. Disable = Validator turned off.
Validator Action -
Retry Form* - Label reprinted if error detected.
N/A
Automatically set during Auto Calibrate.
Automatically set during Auto Calibrate.
Automatically set after power up, while printing and when
printhead is opened then closed.
Automatically set during Auto Calibrate.
Automatically set during Auto Calibrate.
Automatically set during Auto Calibrate.
