Chapter 3
VALIDATOR

VALIDATOR Submenus

NOTE: The Validator menu will only display on the control panel if a validator
Validator Report
When selected, prints a report of the validation statistics since the printer was
turned on or since the last data reset.
Auto Report
This option allows you to disable or enable an automatic validator report
printout after a batch job. You can determine the end of a batch job in two
ways:
•
by using an Execute command to determine end of batch job, or
•
a timeout of more than 10 seconds.
The options are Disable (the factory default) and Enable.
Clear Data
This item initiates an action. When selected, the printer will reset all defined
validator counters. This action must be confirmed before the action is taken.
Good Barcodes
This is a display item only. It indicates the number of bar code reports sent
from the validator since the last data clear operation. After a clear operation,
the value is shown as zero.
Good Forms
This is a display item only. It indicates the number of good forms printed since
the last data clear operation. A form is defined by the current height as set in
the menus. After a clear operation, the value is shown as zero.
Overstrike Forms
This is a display item only. It indicates the number of overstrike/bad forms that
contained a bar code that fell below the minimum acceptable level since the
last data clear operation. If no data has been received since the last clear
operation, this field will be zero.
110
is installed.
Also, if you have previously enabled the validator and have stored a
printer configuration and then you disconnect the validator, the LCD
will display a warning that the validator is disabled.
For detailed information about the validator, please refer to the Online
Data Validator User's Manual.
