Printer Options
Options are offered with the printer to enhance its capabilities and to provide a
large degree of application flexibility. A description of the option complement
is given below. Field-installable options include installation instructions.

Hardware Options

Memory Expansion
The printer internal Flash memory can be upgraded from a 4MB SIMM to a
10MB SIMM, providing additional memory for forms, logos, and fonts.
The internal DRAM memory can be upgraded from a 8MB SIMM to a 16MB
SIMM, providing additional memory for longer label formats.
The printer can be ordered with either or both memory options installed or can
be field installed by an authorized service representative at a later date.
Media Cutter
The printer may be ordered with a cutter mechanism installed (for cutting tags
and label liner), or the option can be installed by an authorized service
representative at a later date. Once installed, the printer can be configured to
automatically cut media after each or a specified number of labels is printed.
A Standard Duty 4 inch model and Heavy-Duty 4, 6 and 8 inch cutter models
are available. See Appendix A for details.
Media Cutter Tray
This option is used exclusively with the media cutter option to collect cut
labels or tag stock. This option can be field installed by the operator.
Online Data Validator (ODV™)
This option provides the capability for verifying printed barcode quality during
the printing process.
The printer may be ordered with the Online Barcode Validator installed, or the
option can be field installed by an authorized service representative.
Internal Rewinder
The internal rewinder supports Peel-Off and Batch Rewind Media Handling
modes. The printer can be ordered with a rewinder or it can be field installed
at a later date by an authorized service representative.
