Chapter 4
ANSI Emulation
Character Set
This parameter selects a character set for the ANSI emulation.
Note that when 0876 OCR-A or 0877 OCR-B is selected as the
print language, the Font Attributes Typeface parameter is changed
to OCR-A or OCR-B, respectively. Character sets are shown in
detail in the Character Sets Reference Manual .
Printer Select
•
ON = DC1/OFF = DC3 (default). Disables the printer when a
DC1 control code is received, and enables the printer when a
DC3 control code is received.
•
Disable. Ignores the DC1 and DC3 control codes.
ESC c Sequence
•
Enable (default). An ESC c code received from the host resets
the printer parameters to the factory defaults.
•
Disable. An ESC c code received from the host is ignored.
Reset Cmd CFG Ld
When the printer receives a host data stream reset command
(ESC @ or ESC[K) in addition to resetting printer variables, the
selected configuration will be loaded.
•
Disable (default). The active emulation parameters are loaded
when the reset command is executed.
•
Power-Up Config. The power-up configuration is loaded when
the reset command is executed.
•
Current Config. The currently selected configuration is loaded
when the reset command is executed.
•
Factory Config. The factory installed configuration is loaded
when the reset command is executed.
218
