Chapter 2
Connect The Interface And Power Cables
Figure 23. Optional Interfaces for the Auxiliary I/O
1. Remove the cover from the I/O connector you have selected.
2. Attach the I/O cable connector to the printer interface
3. Guide the AC power cable up through the hole in the lower right
4. Thread the power cable inside the bracket where the gas
5. Plug the power cable into the printer AC power connector, then
42
Coax/Twinax
connector.
back corner of the cabinet (see Figure 19.)
spring is attached.
into the AC power outlet.
Network
10/100Base-T
