Chapter 4
ANSI Emulation
Character Set
This parameter selects a character set for the ANSI emulation. Note that
when 0876 OCR-A or 0877 OCR-B is selected as the print language, the Font
Attributes Typeface parameter is changed to OCR-A or OCR-B, respectively.
Character sets are shown in detail in the Character Sets Reference Manual.
Printer Select
•
ON = DC1/OFF = DC3 (default). Disables the printer when a DC1 control
code is received, and enables the printer when a DC3 control code is
received.
•
Disable. Ignores the DC1 and DC3 control codes.

ESC c Sequence

•
Enable (default). An ESC c code received from the host resets the printer
parameters to the factory defaults.
•
Disable. An ESC c code received from the host is ignored.
Reset Cmd CFG Ld
When the printer receives a host data stream reset command
(ESC @ or ESC[K) in addition to resetting printer variables, the selected
configuration will be loaded.
•
Disable (default). The active emulation parameters are loaded when the
reset command is executed.
•
Power-Up Config. The power-up configuration is loaded when the reset
command is executed.
•
Current Config. The currently selected configuration is loaded when the
reset command is executed.
•
Factory Config. The factory installed configuration is loaded when the
reset command is executed.

Received CR

•
Observe (default). A CR code received from the host is handled as a
carriage return.
•
Ignore. A CR code received from the host is ignored.

Received DEL

•
Observe (default). A DEL code received from the host is handled as a
Delete command.
•
Ignore. A DEL code received from the host is ignored.

Private Mode

Determines the default type of character set (Set 1 or Set 2). This can also be
set by ESC sequences ESC [>5h and ESC [>5l. Refer to these descriptions in
the ANSI Programmer's Reference Manual for further details.
