Chapter 2
Printer Component Locations
Printer Component Locations
Familiarize yourself with the names and locations of the printer
components, shown in Figure 4 before continuing with the rest of
the installation procedures.
Ribbon Spool
Hub Latch
Tractor Lock
Ribbon Path
Loading Diagram
Figure 4. Printer Component Locations
24
Splined Shaft
Paper
Support
Tractor
Hammer Bank
Cover and
Ribbon Mask
Vertical
Position Knob
Forms
Thickness
Lever
Ribbon
Guide
