Chapter 4
Main Menu
Brief descriptions follow for the first-level configuration menu
options:
•
CONFIG. CONTROL — These options allow you to save, print,
load, delete, name, and reset entire sets of configuration
parameters.
•
ACTIVE IGP EMUL — This menu allows you to select the PGL
or VGL emulation from the menu if IGP is installed.
•
EMULATION — This menu allows you to configure the options
which are available for the current operating (active) emulation.
For example, if LinePrinter+ is the active emulation, then the
LinePrinter+ emulation options can be configured using this
menu.
•
MAINT/MISC — These options provide miscellaneous
functions, such as printing a hex dump, selecting a display
language, setting the lock key, and choosing whether the
printer will power up in offline or online mode.
•
HOST INTERFACE — These options allow you to select either
the Serial RS-232, Serial RS-422, Centronics
Dataproducts
1284 parallel, Auto Switching, Coax or Twinax interface for the
printer. This menu also allows you to configure several
parameters for each interface.
•
NETWORK SETUP — This option allows you to select from
Ethernet Address options and Ethernet Parameters options.
•
PRINTER CONTROL — These options allow you to select
several operating parameters for the printer, such as the speed
at which paper will advance when slewing.
•
DIAGNOSTICS — These options include the diagnostic tests,
system memory, and statistics of the printer.
•
RIBBONMINDER — The options in this submenu allow you to
enable the RibbonMinder
100
®
parallel and Long Lines, Ethernet
™
feature and set its parameters.
®
parallel,
™ ®
, IEEE
