Chapter 2
Set The Top-Of-Form
Figure 43. Aligning the First Print Line with the TOF Indicator
5. Locate the TOF indicator. It is a small tab located on both the
right and left tractor doors.
6. Turn the vertical position knob to align the top of the first print
line with the TOF indicator. For best print quality, it is
recommended that the top-of-form be set at least 1/2 inch
below the perforation.
NOTE: For exact positioning, press the Up or Down Arrow keys to
60
TOF Indicator
move the paper vertically in 1/72 inch increments. The keys
work in both online and offline mode.
Perforation
Vertical
Position
Knob
