Chapter 2
Install Optional Components

Quick Access Cover (Pedestal Models)

Quick Access Cover
Figure 40. The Quick Access Cover on the Pedestal Model
Lever
(Pushed Up)
Paper Exiting the Rear of Printer
If your pedestal model is equipped with the quick access cover, you
may choose how the paper exits the printer. Pushing the lever up
on the quick access cover allows the paper to exit the rear of the
printer similar to a regular pedestal model. Pulling the lever down
allows the paper to exit the top of the printer for demand printing.
58
Lever
(Pulled Down)
Paper Exiting the Top of Printer
Figure 41. Paper Exit Options
Lever
