Chapter 2
Install Basic Components
2. Feed the paper up through the paper slot. Hold the paper in
place with one hand (to prevent it from slipping down through
the paper slot) while pulling it through from above with your
other hand.
Left Tractor Lock
Figure 30. Loading Paper onto the Left Tractor Sprockets
3. Pull the paper above and behind the ribbon mask, which is a
silver metal strip with a clear plastic edge protector.
4. Load the paper on the left tractor sprockets.
5. Close the tractor door.
48
Left Tractor Door
Paper
