Chapter 4
IPDS Emulation
Your IPDS printer emulates the IBM 4234 twinax models 008
and 012.
IPDS Twinax printers can only print IPDS data streams and nothing
else. Even a simple job, such as a screen print, is IPDS data in a
twinax attachment. Because the printer definition on a twinax host
is either set automatically (by auto configuration) or manually, the
printer type is already known.
NOTE: A general discussion about starting and stopping IPDS can

Font Size

This parameter chooses the font size which will be used by IPDS.
•
•
•

Graphics Quality

This parameter chooses the print quality of graphics.
•
•
•
222
be found in the IBM 4234 Product and Programming
Reference Manual (GC31-3879). Sending a non-IPDS data
stream to an IPDS printer and vise versa will result in a
hung spool file or writer.
Select By Host (default). The font ID is only affected by host
commands.
Standard. The font ID is converted to a decompressed font ID.
Compressed. The font ID is converted to a compressed font
ID.
High (default). Graphics are printed at 144 dot rows per inch.
Select By Host. The application decides the quality of the
graphics.
Low. Graphics are printed at 72 dot rows per inch.
