Chapter 4
IGP/PGL Emulation
I-2/5 Selection
This option is added to be compatible with a special IGP-X00
customization. Usually, if I-2/5 barcodes have an odd number of
digits, a leading zero is inserted in front of the data. However, this
special IGP-X00 customization gives you the option of adding a
space character at the end of the barcode instead.
•
•
•
•
AI 00 Spaces
This option is designated for EAN/UCC-128 barcodes whose
application identifier (AI) is 00.
•
•
Select SO Char
Allows you to specify a decimal code from 0 through 255 to be used
in place of SO (Shift Out) as the control code. This allows access
for the alternate set of control function characters. See the
description of the Code 128 barcodes in the IGP/PGL
Programmer's Reference Manual for details.
114
Leading Zero (default). A leading zero is inserted in front of the
data.
Trailing Space. A space is inserted at the end of the data.
X2 DPD. When selected, an I-2/5 barcode with an X2
magnification will use the specially configured ratios 3:3:6:5
rather than 3:6:9:12 for compatibility issues.
Modulo 7 CD. The I-2/5 barcode uses a modulo 7 check digit
instead of the default modulo 10 check digit.
Disable (default). The printable data field is printed with the AI
enclosed in parentheses. This is the standard EAN/UCC-128
format.
Enable. The printable data field is printed with the UCC fields
separated by spaces. This option is IGP-X00 compatible.
