INFO
Modbus RTU is a communication protocol based on a Big Endian byte order. Therefore, the 16-bit register
addresses are transmitted with the most significant byte first. However, the data port is in the case of
Robotiq products based on the Little Endian byte order. As such, the data parts of Modbus RTU messages
are sent with the less significant byte first.
TIP
Modbus RTU specifications and details can be found at www.modbus.org.
4.7.1. Connection Setup
The following table describes the connection requirements for controlling the gripper using the Modbus RTU protocol.
Robot Output / Gripper Input First Register
Robot Input / Gripper Output First Register
1 Various converters are available in the Spare Parts, Kits and Accessories section.
These parameters can be adjusted using the Robotiq User Interface.
2
Each register (word - 16 bits) of the Modbus RTU protocol is composed of 2 bytes (8 bits) from the gripper. The first gripper output
Modbus register(0x07D0) is composed from the first 2 Robotiq Gripper bytes (byte 0 and byte 1).
Robotiq Hand-E C10 Gripper Instruction Manual
PROPRIETY
Physical Interface
Baud Rate 2
Data Bits
Stop Bit
2
Parity 2
Supported Functions
Exception Responses
Slave ID 2
Termination Resistor 2
DEFAULT VALUE
RS-485 1
115,200 bps
8
1
None
Read Input Registers (FC04)
Preset Multiple Registers (FC16)
Master read & write multiple registers (FC23)
Not supported
0x0009 (9)
0x03E8 (1000)
0x07D0 (2000)
120 ohms
