INFO
The activation will allow the gripper to adjust to any fingers/fingertips. No matter what is the size and/or
shape of the fingers/fingertips, 0 will always be fully opened and 255 fully closed, with a quasi-linear
relationship between the two values.
4.3.5. Register: SPEED
Address: Byte 4
This register is used to set the gripper closing or opening speed in real time, however, setting a speed will not initiate a motion.
0x00 - Minimum speed
l
0xFF - Maximum speed
l
4.3.6. Register: FORCE
Address: Byte 5
The force setting defines the final gripping force for the gripper. The force will fix the maximum current sent to the motor . If the
current limit is exceeded, the fingers stop and trigger an object detection notification. Please refer to the Picking Features section
for details on force control.
0x00 - Minimum force
l
0xFF - Maximum force
l
INFO
Register bytes 6 to 15 are reserved and should be set to 0.
4.4. Robot Input Registers and Status
4.4.1. Register: GRIPPER STATUS
Address: Byte 0
Bits
7
6
Symbol
Bits
7
6
Symbol
Bits
7
6
5
Symbols
gOBJ
gSTA
5
4
3
2
rSP
5
4
3
2
rFR
4
3
2
1
gGTO
Reserved
Robotiq Hand-E C10 Gripper Instruction Manual
1
0
1
0
0
gACT
46
