0x0 - Normal.
l
0x1 - Emergency auto-release.
l
CAUTION
The automatic release is meant to disengage the gripper after an emergency stop of the robot.
The automatic release is not intended to be used under normal operating conditions.
Automatic release requires the rACT to be cleared (rACT == 0) then set (rACT == 1).
rARD
Auto-release direction. When auto-releasing, rARD commands the direction of the movement. The rARD bit should be set prior to
or at the same time as the rATR bit, as the motion direction is set when the auto-release is initiated.
0x0 - Closing auto-release
l
0x1 - Opening auto-release
l
4.3.2. Register: GRIPPER OPTIONS
Address: Byte 1
4.3.3. Register: GRIPPER OPTIONS 2
Address: Byte 2
4.3.4. Register: POSITION REQUEST
Address: Byte 3
This register is used to set the target position for the gripper's fingers. The positions 0x00 and 0xFF correspond respectively to the
fully opened and fully closed mechanical stops. For detailed finger trajectory, see the Specifications section.
0x00 - Open position, 40 mm opening
l
0xFF - Closed
l
Opening / count: ≈0.16 mm for 40 mm stroke
l
Robotiq Hand-E C10 Gripper Instruction Manual
Bits 7 6
Symbol
Bits 7 6
Symbol
Bits 7 6
Symbol
5 4 3 2 1
Reserved
5 4 3 2 1
Reserved
5 4 3 2 1
rPR
0
0
0
