Sequence Output Instructions

3-4 Sequence Output Instructions
3-4-1

OUTPUT: OUT

Purpose
Ladder Symbol
Variations
In the following example, CIO 000001 is turned ON when CIO 000000 is ON
and bit 5 of D00010 is OFF.
OR TST(350) and OR TSTN(351)
In the following example, CIO 000001 is turned ON when CIO 000000 or bit 3
of D00010 is ON.
In the following example, CIO 000001 is turned ON when CIO 000000 is ON
or bit 3 of D00010 is OFF.
Outputs the result (execution condition) of the logical processing to the speci-
fied bit.
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation
Immediate Refreshing Specification (See note.)
Note Immediate refreshing is not supported by CS1D CPU Units.
&3
&5
&3
&3
Section 3-4
OUT
Not supported.
Not supported.
!OUT
185
