Sequence Input Instructions
3-3-9

Differentiated and Immediate Refreshing Instructions

Instruction variation
Ordinary LD, AND, OR, LD NOT,
AND NOT, OR NOT
OUT, OUT NOT
Differentiated up @LD, @AND, @OR
Differentiated down %LD, %AND, %OR
Immediate refresh !LD, !AND, !OR, !LD NOT,
!AND NOT, !OR NOT
!OUT, !OUT NOT
Differentiated up / !@LD, !@AND, !@OR
immediate refresh
Differentiated down / !%LD, !%AND, !%OR
immediate refresh
The LOAD, AND, and OR instructions have differentiated and immediate
refreshing variations in addition to their ordinary forms, and there are also two
combinations available.
The LOAD NOT, AND NOT, OR NOT, OUT, and OUT NOT instructions have
immediate refreshing variations in addition to their ordinary forms.
The I/O timing for data handled by instructions differs for ordinary and differ-
entiated instructions, immediate refreshing instructions, and immediate
refreshing differentiated instructions.
Ordinary and differentiated instructions are executed using data input by pre-
vious I/O refresh processing, and the results are output with the next I/O pro-
cessing. Here "I/O refreshing" means the data exchanged between the CPU's
internal memory and the I/O Unit.
In addition to the above I/O refreshing, an immediate refresh instruction
exchanges data with the I/O Unit for those words that are accessed by the
instruction. An immediate refresh instruction refreshes eight bits simulta-
neously (leftmost or rightmost eight bits) in addition to the specified bit.
Immediate refresh instructions cannot be used for Units on Slave Racks.
Mnemonic
The ON/OFF status of the specified bit
is taken by the CPU with cyclic refresh-
ing, and it is reflected in the next instruc-
tion execution.
After the instruction is executed, the ON/
OFF status of the specified bit is output
with the next cyclic refreshing.
The instruction is executed once when
the specified bit turns from OFF to ON
and the ON state is held for one cycle.
The instruction is executed once when
the specified bit turns from ON to OFF
and the ON state is held for one cycle.
The input data for the specified bit is
taken by the CPU and the instruction is
executed.
After the instruction is executed, the
data for the specified bit is output.
The input data for the specified bit is
refreshed by the CPU, and the instruc-
tion is executed once when the bit turns
from OFF to ON and the ON state is
held for one cycle.
The input data for the specified bit is
refreshed by the CPU, and the instruc-
tion is executed once when the bit turns
from ON to OFF and the ON state is
held for one cycle.
Function
Section 3-3
I/O refresh
Cyclic refreshing
Before instruction execu-
tion
After instruction execution
Before instruction execu-
tion
