Omron SYSMAC CJ - REFERENCE MANUAL 01-2008 Reference Manual page 215

Sequence Input Instructions
176
Coding Example (1)
Instruction
LD
AND NOT
LD NOT
AND NOT
OR LD
LD
AND
OR LD
.
.
OUT
Coding Example (2)
Instruction
LD
AND NOT
LD NOT
AND NOT
LD
AND
.
.
OR LD
OR LD
.
.
OUT
The OR LOAD instruction can be used repeatedly. In programming method
(2) above, however, the number of OR LOAD instructions becomes one less
than the number of LOAD and LOAD NOT instructions before that.
In method (2), make sure that the total number of LOAD and LOAD NOT
instructions before OR LOAD is not more than eight. To use nine or more, pro-
gram using method (1). If there are nine or more with method (2), then a pro-
gram error will occur during the program check by the Peripheral Device.
Coding
Address
000100
000101
000102
000103
000104
000105
Second LD: Used for first bit of next block connected in series to previous block.
Operand
000000
000001
000002
000003
---
000004
000005
---
.
.
000501
Operand
000000
000001
000002
000003
000004
000005
.
.
---
---
.
.
000501
Instruction
LD
AND NOT
LD
AND
OR LD
OUT
Section 3-3
Operand
000000
000001
000002
000003
---
000501
