General Instruction Characteristics

1-1 General Instruction Characteristics
1-1-1

Program Capacity

2
The program capacity tells the size of the user program area in the CPU Unit
and is expressed as the number of program steps. The number of steps
required in the user program area for each of the CS/CJ-series instructions
varies from 1 to 7 steps, depending upon the instruction and the operands
used with it.
CS Series
The following tables show the maximum number of steps that can be pro-
grammed in each CS-series CPU Unit.
• CS1-H CPU Units
Model
CS1H-CPU67H
CS1H-CPU66H
CS1H-CPU65H
CS1H-CPU64H
CS1H-CPU63H
CS1G-CPU45H
CS1G-CPU44H
CS1G-CPU43H
CS1G-CPU42H
• CS1 CPU Units
Model
CS1H-CPU67-E
CS1H-CPU66-E
CS1H-CPU65-E
CS1H-CPU64-E
CS1H-CPU63-E
CS1G-CPU45-E
CS1G-CPU44-E
CS1G-CPU43-E
CS1G-CPU42-E
• CS1D CPU Units for Single-CPU Systems
Model
CS1D-CPU67H
CS1D-CPU65H
CS1D CPU Units for Duplex-CPU Systems
Model
CS1D-CPU42S
CS1D-CPU44S
CS1D-CPU65S
CS1D-CPU67S
CJ Series
The following tables show the maximum number of steps that can be pro-
grammed in each CJ-series CPU Unit.
Program capacity
250K steps
120K steps
60K steps
30K steps
20K steps
60K steps
30K steps
20K steps
10K steps
Program capacity
250K steps
120K steps
60K steps
30K steps
20K steps
60K steps
30K steps
20K steps
10K steps
Program capacity
250K steps
60K steps
Program capacity
10K steps
30K steps
60K steps
250K steps
Section 1-1
I/O points
5,120
1,280
960
I/O points
5,120
1,280
960
I/O points
5,120
I/O points
960
1,280
5,120
