Sequence Output Instructions
Applicable Program Areas
Operand Specifications
Description
Flags
Precautions
186
Block program areas
Not allowed OK
Area
CIO Area CIO 000000 to CIO 614315
Work Area W00000 to W51115
Holding Bit Area H00000 to H51115
Auxiliary Bit Area A44800 to A95915
Timer Area ---
Counter Area ---
TR Area TR0 to TR15
DM Area ---
EM Area without bank ---
EM Area with bank ---
Indirect DM/EM ---
addresses in binary
Indirect DM/EM ---
addresses in BCD
Constants ---
Data Registers ---
Index Registers ---
Indirect addressing ,IR0 to ,IR15
using Index Registers
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to ,IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
If there is no immediate refreshing specification, the status of the execution
condition (power flow) is written to the specified bit in I/O memory. If there is
an immediate refreshing specification, the status of the execution condition
(power flow) is also written to the Basic Output Unit's output terminal in addi-
tion to the output bit in I/O memory.
There are no flags affected by this instruction.
Immediate refreshing (!) can be specified for OUT and OUT NOT. An immedi-
ate refresh instruction updates the status of the output terminal just after the
instruction is executed for the Basic Output Unit (but not for Basic Output
Units on Slave Racks or for C200H Group 2 Multi-point Input Units), at the
same time as it writes the status of the execution condition (power flow) to the
specified output bit in I/O memory.
OUT cannot be used for addresses in the DM and EM Areas. Use OUTB(534)
instead.
Step program areas Subroutines
OK
OUT bit operand
Section 3-4
Interrupt tasks
OK
