Omron SYSMAC CJ - REFERENCE MANUAL 01-2008 Reference Manual page 144

Instruction Functions
Instruction Symbol/Operand
Mnemonic
Code
ONE CYCLE AND WAIT(805)
WAIT
WAIT
805
ONE CYCLE AND WAIT(805)
WAIT
B
WAIT
805
B: Bit operand
ONE CYCLE AND WAIT(805) NOT
WAIT (NOT) B
WAIT NOT
805 B: Bit operand
HUNDRED-MS TIMW(813)
TIMER WAIT
TIMW
813
(BCD)
N: Timer number
SV: Set value
TIMWX
TIMWX(816)
816
(Binary)
(CS1-H, CJ1-H,
CJ1M, or CS1D
only)
N: Timer number
SV: Set value
If the execution condition is ON for WAIT(805), the rest of the
instruction in the block program will be skipped.
Execution
condition
If the operand bit is OFF (ON for WAIT NOT(805)), the rest of the
instructions in the block program will be skipped. In the next cycle,
none of the block program will be executed except for the execution
condition for WAIT(805) or WAIT(805) NOT. When the execution condi-
tion goes ON (OFF for WAIT(805) NOT), the instruction from
WAIT(805) or WAIT(805) NOT to the end of the program will be exe-
cuted.
If the operand bit is OFF (ON for WAIT NOT(805)), the rest of the
instructions in the block program will be skipped. In the next cycle,
none of the block program will be executed except for the execution
condition for WAIT(805) or WAIT(805) NOT. When the execution condi-
tion goes ON (OFF for WAIT(805) NOT), the instruction from
WAIT(805) or WAIT(805) NOT to the end of the program will be exe-
cuted.
Delays execution of the block program until the specified time has
N
elapsed. Execution continues from the next instruction after
SV
TIMW(813)/TIMWX(816) when the timer times out.
N
SV
BEND
C
Function
Execution Execution
Execution
condition
condition
condition
ON
OFF OFF
"A"
executed.
"B" executed.
"C" "C" "C" executed.
executed. executed.
Wait
SV: 0 to 999.9 s for BCD and
0 to 6,553.5 s for binary
"A"
executed.
SV
Time elapsed.
preset.
"B" executed.
"C" executed.
Section 2-2
Location Page
Execution
condition
Block program 1203
Required
Block program 1203
Required
Block program 1203
Required
Block program 1207
Required
105
