Omron SYSMAC CJ - REFERENCE MANUAL 01-2008 Reference Manual page 307

Timer and Counter Instructions
Applicable Program Areas
Operands
Operand Specifications
268
Block program areas
Not allowed OK
D1: Completion Flag
Bit 0 of D1 acts as the Completion Flag for TIML(542)/TIMLX(553).
15
D1
D2: PV Word
D2+1 and D2 contain the 8-digit binary or BCD PV. (D2 and D2+1 must be in
the same data area.) The PV can range from #00000000 to #99999999 for
TIML(542) and &00000000 to &4294967294 (decimal) or #00000000 to
#FFFFFFFF (hexadecimal) for TIMLX(553).
D2
S: SV Word
S+1 and S contain the 8-digit binary or BCD SV. (S and S+1 must be in the
same data area.) The SV must be between #00000000 to #99999999 for
TIML(542) and &00000000 to &4294967294 (decimal) or #00000000 to
#FFFFFFFF (hexadecimal) for TIMLX(553).
S
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Step program areas Subroutines
OK
0
Do not use.
D2+1
S+1
D1
CIO 0000 to CIO 0000 to CIO 6142
CIO 6143
W000 to W511 W000 to W510
H000 to H511 H000 to H510
A448 to A959 A448 to A958
--- ---
--- ---
D00000 to D00000 to D32766
D32767
E00000 to E00000 to E32766
E32767
En_00000 to En_00000 to En_32766
En_32767
(n = 0 to C)
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Section 3-6
Interrupt tasks
Not allowed
Completion Flag
D2
S
D2 S
A000 to A958
T0000 to T4094
C0000 to C4094
