3-13-5 EXCLUSIVE OR: XORW(036)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
556
When the execution condition CIO 00000000 is ON, the logical OR is taken of
corresponding bits in CIO 0021, CIO 0020 and CIO 0301, CIO 0300 and the
results will be output to corresponding bits in D00501 and D00500.
S : 0020 CH
1
S +1: 0021 CH
1
Note: The vertical arrow indicates logical OR.
Takes the logical exclusive OR of corresponding bits in single words of word
data and/or constants.
XORW(036)
I
1
I
2
R
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
OK OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
S : 0300 CH
2
S +1: 0301 CH
2
I
: Input 1
1
I
: Input 2
2
R: Result word
Step program areas Subroutines
OK
I
1
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
Section 3-13
D: D00500
D+1: D00501
XORW(036)
@XORW(036)
Not supported.
Interrupt tasks
OK
I R
2
A448 to A959
