Table Data Processing Instructions

3-17-7 GET RECORD NUMBER: GETR(636)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
Returns the record number of the record at the PLC memory address con-
tained in the specified Index Register.
GETR(636)
N
IR
D
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
OK
N: Table number
Indicates the table number. N must be between 0 and 15.
IR: Index Register
Indicates the desired Index Register. D must be IR0 to IR15.
D: Destination word
Indicates the word where the record number will be written.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
N: Table number
IR: Index Register
D: Destination word
Step program areas
OK OK
N IR
---
---
---
---
---
---
---
---
---
---
---
0 to 15 ---
---
Section 3-17
GETR(636)
@GETR(636)
Not supported.
Subroutines Interrupt tasks
OK
D
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A448 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
DR0 to DR15
