5�5�- ETHERNET - Wi-Fi - Bluetooth
(Models CVM-E3-MINI-xxx-WiEth)
Note:
"ANNEX A - CONFIGURATION MENUS"
Press the
screens for Ethernet, Wi-Fi and Bluetooth
5�5�1� ETHERNET COMMUNICATIONS: DHCP CONFIGURATION
You can enable or disable DHCP on this screen. If DHCP is enabled (default configuration), the IP
address is assigned dynamically via a central server. No other parameters need to be set up.
Press the
screen.
The
 Configuration values
To validate the value, press the
Press key
5�5�2� ETHERNET COMMUNICATIONS: IP ADRESS
You can set up (DHCP disabled) or view the IP address on this screen.
Press the key
50
keys simultaneously from any display screen to show the settings and display
key for 3 seconds to enter the edit mode. The prog icon will flash on the left of the
key is used to browse the different options:
Table 20:Configuration values: DHCP Configuration�
Possible values
to access the next programming step.
to display the value.
COMMUNICATIONS SCREENS
®
shows the full settings tree structure.
communications.
®
DHCP Configuration
no DHCP is not enabled.
YES DHCP is enabled
key for 3 seconds; the prog icon will stop flashing.
CVM-E3-MINI
Instruction Manual
