VLT® Refrigeration Drive FC 103
Operating Guide
Parameter
Parameter 1-23 Motor Frequency
Parameter 1-25 Motor Nominal Speed
Parameter 1-53 Model Shift Frequency
Parameter 1-56 U/f Characteristic
Parameter 6-15 Terminal 53 High Ref./Feedb. Value
Parameter 14-37 Fieldweakening Speed

11.4 Required Parameter Settings for Drive Options

On performing a factory reset on the drive, all drive parameters revert to their factory default value. Several drive options have pa-
rameter settings that must be configured differently from the factory default values in order for the options to perform properly.
Table 131: Parameter Settings for the Passive Filter Option (Typecode Character 7 = P/H/L/U)
Parameter
Parameter 5-02 Terminal 29 Mode
Parameter 5-10 Terminal 18 Digital Input
Parameter 5-31 Terminal 29 Digital Output
Parameter 14-51 DC-link Compensation
Table 132: Parameter Settings for the dU/dt Filter Option (Typecode Character 18 = D/1)
Parameter
Parameter 5-10 Terminal 18 Digital Input
Parameter 14-52 Fan Control
This fan setting applies only to D9h and D10h models.
1
Table 133: Parameter Settings for the Sine-wave Filter Option (Typecode Character 18 = S/2)
Parameter
Parameter 5-10 Terminal 18 Digital Input
Parameter 14-55 Output Filter
Table 134: Parameter Settings for the Indicator Light + Reset Button Option (Typecode Character 28–29 = D1/DA/DB/DC/DD/DE)
Parameter
Parameter 5-40 Function Relay [1]
Parameter 5-40 Function Relay [2]
Parameter 5-11 Terminal 19 Digital Input
Danfoss A/S © 2020.09
International default value
50 Hz
1400 RPM
16.7
50 Hz
1500 RPM
1400 RPM
Change value to
[1] Output
[7] External Interlock
[188] AHF Capacitor Connect
[0] Off
Change value to
[7] External Interlock
[3] On 100%
Change value to
[7] External Interlock
[2] Sine-Wave Filter Fixed
North American default value
60 Hz
1680 RPM
20.0
60 Hz
1800 RPM
1680 RPM
(1)
Change value to
[5] Running
[9] Alarm
[1] Reset
AQ357954340588en-000201 / 130R0881 | 169
Appendix
