VLT® Refrigeration Drive FC 103
Operating Guide
• Contactor
• Molded-case circuit breaker (MCCB)

10.8.1 Panel Fuses

Panel fuses are an option for upstream protection, and can be ordered as either a UL class fuse for UL variant or a gG fuse for IEC
variant.
Table 103: Panel Fuses for N110K–N315 Models, 380–480 V
N110
IEC (Type gG) 250 A/500 V
Mersen P/N NH1GG50V250
UL (Class J/L/T) 300 A/600 V
Mersen P/N A4J300
Table 104: Panel Fuses for N355–N560 Models, 380–480 V
N355
IEC (Type gG) 800 A/500 V
Mersen P/N NH4GG50V800
800 A/600 V
UL (Class J/L/T)
Mersen P/N A4BY800
Table 105: Panel Fuses for N110–N315 Models, 525–690 V
N110
IEC (Type gG) 250 A/690 V
Mersen P/N NH2GG69V250
UL (Class J/L/T) 175 A/600 V
Mersen P/N A4J175
Table 106: Panel Fuses for N400–N630 Models, 525–690 V
N400
IEC (Type gG) 500 A/690 V
Mersen P/N NH3GG69V500
UL (Class J/L/T) 600 A/600 V
Mersen P/N A4J600
Table 107: Panel Fuses for N710–N800 Models, 525–690 V
IEC (Type gG)
ABB P/N
UL (Class J/L/T)
156 | Danfoss A/S © 2020.09
N132 N160
315 A/500 V 355 A/500 V
NH2GG50V315 NH2GG50V355
350 A/600 V 400 A/600 V
A4J350 A4J400
N400 N450
1000 A/500 V 1000 A/500 V
NH4GG50V1000 NH4GG50V1000
1000 A/600 V 1000 A/600 V
A4BY1000 A4BY1000
N132 N160
250 A/690 V 250 A/690 V
NH2GG69V250 NH2GG69V250
200 A/600 V 250 A/600 V
A4J200 A4J250
N450
500 A/500 V
NH3GG69V500
600 A/600 V
A4J600
N710
1000 A/690 V
OFAA4AM1000
1000 A/600 V
N200 N250
425 A/500 V 630 A/500 V
NH3GG50V425 NH3AGG50V630
500 A/600 V 600 A/600 V
A4J500 A4J600
N500
1000 A/500 V
NH4GG50V1000
1100 A/600 V
A4BY1100
N200 N250
315 A/690 V 355 A/690 V
NH2GG69V315 NH3GG69V355
350 A/600 V 400 A/600 V
A4J350 A4J400
N500 N560
630 A/500 V 800 A/500 V
NH4GG69V630 NH4GG69V800
650 A/600 V 750 A/600 V
A4BY650 A4BY750
N800
1000 A/690 V
OFAA4AM1000
1100 A/600 V
Specifications
N315
630 A/500 V
NH3AGG50V630
750 A/600 V
AABY750
N560
1250 A/500 V
NH4GG50V1250
1200 A/600 V
A4BY1200
N315
425 A/690 V
NH3GG69V425
500 A/600 V
A4J500
N630
800 A/500 V
NH4GG69V800
800 A/600 V
A4BY800
