Chapter 4 Cabling the Multiple Library Stack
Power Cabling
Table 7 ATL M1500
AC Distribution
Requirements
# of
Library 200-240V 50-60Hz supply voltage
Modules (Europe & international, etc.)
1-5 Connect libraries to one AC
distribution unit rated minimum 10A,
minimum 1.00mm2 <HAR> cord with
minimum 10A plug. Must be 3 wire
grounding plug and wall outlet.
6-9 Select one of the following options:
• Connect no more than 5 libraries to
each of two AC distribution units
rated minimum 10A, minimum
1.00mm2 <HAR> cord with
minimum 10A plug. Must be 3 wire
grounding plug and wall outlet. The
AC distribution units must be
plugged into separate outlets served
by separate circuit breakers or fuses.
• Connect all libraries to one AC
distribution unit rated minimum
10A, minimum 1.00mm2 <HAR> 3
wire cord with 3 wire IEC60309 rated
16A. Must be 3 wire grounding plug
and wall outlet and have a ground
warning label.
• Connect all libraries to one AC
distribution unit rated minimum
10A, minimum 1.00 mm2 <HAR> 3
wire cord permanently wired to the
electrical supply. Must be connected
with a 3 wire cable and have a
ground warning label.
74
Distribution Unit Requirements
ATL StackLink™ Installation Instructions
100-120V 50-60Hz supply voltage
(USA, Canada, Japan, etc.)
Connect libraries to one UL Listed AC
distribution unit rated 15A or 20A, with
a minimum 14AWG 3 wire cord, and a
15A or 20A plug. Must be 3 wire
grounding plug and wall outlet.
Select one of the following options:
• Connect no more than 5 libraries to
each of two AC distribution units
rated 15A or 20A, with a minimum
14AWG 3 wire cord, and a 15A or
20A plug. Must be 3 wire grounding
plug and wall outlet. The AC
distribution units must be plugged
into separate outlets served by
separate circuit breakers or fuses.
• Connect all libraries to one AC
distribution unit rated 20A, with a
minimum 14AWG 3 wire cord, with
a 20A plug. Must be 3 wire
grounding plug and wall outlet.
• Connect all libraries to one AC
distribution unit rated minimum
20A, with a minimum 14AWG 3
wire cord, permanently wired to the
electrical supply.
