Chapter 3 Installing the Libraries

Installing the Libraries in the Rack

Installing the Libraries in the Rack
48
To install the libraries:
The ATL M1500 library weighs approximately 54 lbs (24.5
Warning:
kg). The ATL M2500 library weighs approximately 152 lbs.
(69 kg). At least two people are required to lift and install
these libraries.
1 Unpack the library modules, referring to the ATL M1500 Library
Unpacking Instructions (PN 6421002) and the ATL M2500 Library
Unpacking Instructions (PN 6423000).
Make sure to remove the StackLink cover plate from
Caution:
each library.
2 Verify that the rack mount shelves are level and securely fastened to
the rack.
3 With the help of another person, lift the library module onto the rack
mount shelves.
When sliding the library into the rack, be very careful
Caution:
not to abrade or disconnect the ribbon cable that
connects the vertical shuttle assembly to the control
board on the motor assembly. See
location of this cable.
4 Slide the library all the way into the rack.
5 Press the buttons next to the magazine access doors and open the
doors.
6 Locate the access holes behind the left magazine access doors (see
figures
34
and 35). These holes provide access to the rack mount
clamp screws.
ATL StackLink™ Installation Instructions
3
