2 Route the belt connecting the counterweight and carriage up and
over the top of the vertical shuttle assembly, making sure not to twist
the belt.
3 Slide the carriage onto the top of the vertical shuttle assembly,
engaging the guide wheels of the carriage with the vertical rails.
4 Secure the umbilical cable to the underside of the carriage (see
figure 8):
Locate the pin on the underside of the carriage.
a
Slide the umbilical cable underneath the open end of the pin.
b
Rotate the pin until the umbilical cable is held snugly.
c
Tighten the screw to secure the pin.
d
Do not over-tighten the screw.
Caution:
5 Snap the end of the umbilical chain onto the bottom of the carriage
(see figure 8).
6 Connect the end of the umbilical cable to the socket on the carriage
connection board (see
ATL StackLink™ Installation Instructions
Chapter 1 Installing the StackLink
Installing the Carriage/Counterweight Assembly
figure 8).
13
