Chapter 2 Installing the Rack Mount Shelves
Installing the Shelves
Table 5 Shelf
Assembly Matrix
Figure 20 Identifying
the Shelf Extender
Slots
32
Rack Depth
(between flanges)
24.25 in. to 26.75 in.
(617 mm to 680 mm)
26.75 in. to 29.125 in.
(680 mm to 740 mm)
29.125 in. to 31.5 in.
(740 mm to 800 mm)
31.5 in. to 33.875 in.
(800 mm to 860 mm)
33.875 in. to 36.25 in.
(860 mm to 920 mm)
C
B
D
C
D
ATL StackLink™ Installation Instructions
Left Shelf
Shelf
Extender
Slots
Long #2
A & B
Long #1
B & C
Long #2
B & C
Long #1
C & D
Long #2
C & D
A
B
A
C
C
D
D
Right Shelf
Shelf
Extender
Slots
Long #1
A & B
Long #2
A & B
Long #1
B & C
Long #2
B & C
Long #1
C & D
A
A
B
B
