Figure 17 Installing
the Inserts in the
Shelves
3 Screw the inserts into the two outer holes on each end of the
assembled shelves (see
Some of the inserts have either no head or a head that has
Note:
a smaller diameter than the thread; these need to be left
protruding by about 1/8 in. (3 mm). The inserts with
heads should be tightened fully.
Inserts
ATL StackLink™ Installation Instructions
Chapter 2 Installing the Rack Mount Shelves
figure
17).
Installing the Shelves
27
