Figure 34 Rack Mount
Clamp Screw Access
Holes, ATL M1500
Figure 35 Rack Mount
Clamp Screw Access
Holes, ATL M2500
Magazine access door
Magazine access doors
Access holes for rack mount clamp screws
ATL StackLink™ Installation Instructions
Chapter 3 Installing the Libraries
Installing the Libraries in the Rack
Magazine access doo
Access holes for rack
mount clamp screws
49
