Chapter 4 Cabling the Multiple Library Stack
Interlibrary (Control Bus) Cabling
Interlibrary (Control Bus) Cabling
66
The intelligent control bus allows the individual library modules in the
rack to communicate. To connect this bus:
1 Connect the top library module in the rack to the terminator on the
front of the motor assembly, using one of the library control bus
cables provided.
2 Daisy chain the control bus as shown in
control bus cables provided.
3 Connect the bottom library module in the rack to the I
board, using one of the library control bus cables provided.
ATL StackLink™ Installation Instructions
figure
47, using the library
2
C terminator
4
