Chapter 2 Installing the Rack Mount Shelves
Installing the Shelves
Figure 32 Installing
the Rear Shelf Clamps
44
7 Install the clamp strips (see
Position a front shelf clamp (PN 215812) at the front of the front
a
left rack rail, with the bottom of the clamp approximately 15.5
inches (394 millimeters) above the bottom of the rack mount
shelf.
The top of the front shelf clamp must be no more than
Caution:
22.75 in. (580 mm) above the bottom of the rack mount
shelf.
Position a clamp strip (PN 217405) behind the front left rack rail,
b
aligning it with the shelf clamp.
Insert a screw (PN YS42064) through the upper hole in the front
c
shelf clamp, through the rack rail, and into the upper hole in the
clamp strip.
Insert a screw (PN YS42064) through the bottom hole in the front
d
shelf clamp, through the rack rail, and into the bottom hole in the
clamp strip.
ATL StackLink™ Installation Instructions
figure
33):
