Page 1: Unpacking Instructions
Introduction Removing the Library from the Shipping Carton Removing the Remaining Packing Materials Checking the Contents Document 6421002-06 A01, July 2003 Quantum ATL M1500 Unpacking Instructions... - Page 2 Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 6207947-04fN 5...
-
Page 3: Introduction
Introduction Removing the Library from the Shipping Carton This document explains how to unpack a Quantum ATL M1500. The unpacking procedure consists of the following major steps: • Removing the library from the shipping carton • Removing the remaining packing materials •... - Page 4 Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 Figure 1 Removing the Library from the Shipping Carton Plastic straps Remove the accessories kit and set it aside. With the help of a second person, lift the library up and out of the shipping carton.
-
Page 5: Removing The Remaining Packing Materials
(see figure Put on an antistatic wrist strap and clip it to the antistatic stud on the back of the library (near the power supply). Removing the Remaining Packing Materials Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003... - Page 6 Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 Figure 3 Opening the Right Magazine Access Door Figure 4 Removing the Magazine Push the button next to the right magazine access door (see figure The right magazine access door opens.
- Page 7 Do not move or remove the foam pad on the robotic hand until instructed to do so (this occurs during step 13). Removing the Remaining Packing Materials Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 figure...
- Page 8 Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 Figure 7 Removing the Foam Pads that Support the X-Y Tray Left foam pad Right foam pad Move the robotic hand to the back of the library by reaching through the right magazine access door. Grip the steel flange on the “Y”...
- Page 9 Gripping the lower edge of the foam pad, pull to the right and remove it off the robotic hand and out from the library (see figure Pull right and out of the library Removing the Remaining Packing Materials Quantum ATL M1500 Unpacking Instructions Document 6421002-06 A01 July 2003 Steel flange...
-
Page 10: Checking The Contents
Close the magazine access doors. The library is now unpacked and ready to be installed in its final location. Refer to the Quantum ATL M-Series Installation Guide (6423001) for installation instructions. The tape drives and media are sent separately from the Note: library.
