Installing the Motor Assembly

Figure 9 Inserting the
Motor Assembly into
the Vertical Shuttle
Assembly
To secure the motor assembly to the vertical shuttle assembly:
1 Insert the bottom of the motor assembly into the top of the vertical
shuttle assembly, aligning the two holes in the vertical shuttle
assembly with those on the motor assembly (see
These two holes align with
oles in the motor assembly
ATL StackLink™ Installation Instructions
Chapter 1 Installing the StackLink
Installing the Motor Assembly
figure
9).
1
15
