Table 3 Shelf
Assembly Matrix
Figure 15 Identifying
the Shelf Extender
Slots
Rack Depth
(between flanges)
24.50 in. - 26.75 in.
(620 mm - 680 mm)
26.75 in. - 29.125 in.
(680 mm - 740 mm)
29.125 in. - 31.50 in.
(740 mm - 800 mm)
31.50 in. - 33.875 in
(800 mm - 860 mm)
33.875 in. - 36.25 in.
(860 mm - 920 mm)
A
B
ATL StackLink™ Installation Instructions
Chapter 2 Installing the Rack Mount Shelves
Left Shelf
Shelf
Extender
Slots
#2
A & B
#1
B & C
#2
B & C
#1
C & D
#2
C & D
C
D
Installing the Shelves
Right Shelf
Shelf
Extender
Slots
#1
A & B
#2
A & B
#1
B & C
#2
B & C
#1
C & D
25
