Chapter 3 Installing the Libraries
Preparing and Inserting Tape Cartridges
Figure 43 Inserting
DLT Cartridges into a
Magazine
60
3 Insert the cleaning cartridge into the fixed slot behind the left
magazine, orienting it with the label facing outward and the write-
protect switch:
Down, if it is a DLT or SDLT cartridge
Up, if it is an LTO cartridge
4 Insert cartridges into each of the magazine slots:
Orient the cartridges as described in
a
Push each cartridge into a slot until the cartridge retaining latch
b
clicks to hold the cartridge in place.
The magazines are designed so that you cannot insert
Caution:
cartridges incorrectly. Do not try to force the
cartridges into the slots.
Label
Write-protect
5 Insert the magazines into the library, sliding them back until they
click into place.
6 Close the magazine access doors.
ATL StackLink™ Installation Instructions
step
Cartridge
retaining latch
switch
