Chapter 2 Installing the Rack Mount Shelves
Installing the Shelves
Installing the
ATL M2500 Rack
2
Mount Shelves
Table 4 Contents,
ATL M2500 Universal
Rack Mount Kit
30
This section explains how to install the ATL M2500 rack mount shelves.
Checking the Contents of the Rack Mount Kit
Table 4
lists the contents of the ATL M2500 Universal Rack Mount Kit. If
any items are missing, contact Quantum (see
page xix).
Part No.
Description
213468
Insert (9 sq)
213469
Insert (7 sq)
213471
Insert (M6)
213473
Insert (10-32 UNF, 12-24 UNC, or M5)
213474
Insert (1/4 inch diameter)
215812
Front shelf clamp
217405
Clamp strip
215197/02
Universal shelf, right
215198/02
Universal shelf, left
215199/01
Shelf extender, long #1
215200/01
Shelf extender, long #2
215201/01
Rear shelf clamp
YS40403
Plain washer M5
YS41998
Nut, M5 full
YS42064
Countersink hex socket screw M4 x 12 LG
ATL StackLink™ Installation Instructions
Customer Support
on
Qty.
2
12
12
12
12
12
4
2
1
1
1
1
2
8
8
12
