Figure 44 Removing
the Level 2 Left
Magazine
Placing Tape Cartridges in an ATL M2500 Library
To place tape cartridges in an ATL M2500 library:
1 Press the buttons next to the magazine access doors.
The magazine access doors open.
2 Remove the level 1 left magazine:
Grasping the handle at the front of the level 1 left magazine, pull
a
it forward until it stops.
If the magazine stops after the first slot, perform steps
b
2e
to release it.
Remove the level 2 left magazine (see
c
Reach into the library underneath the level 1 left magazine and
d
pull down on the release latch (see
ATL StackLink™ Installation Instructions
Chapter 3 Installing the Libraries
Preparing and Inserting Tape Cartridges
figure
44).
figure
45).
3
2c
through
61
