Document 6421018-02, Ver. 2, Rel. 0, September 2002
User's Guide Addendum -
Fibre Channel Description ...........................................................................3
FC310 Router Operation...............................................................................3
Key to Successful Configuration of the FC310 Option ............................4
Configuration.................................................................................................4
FC310 Configuration Procedure..................................................................4
Upgrading the FC310 Prism Firmware ......................................................7
FC310 Service Software Operation ...........................................................13
Command Syntax ........................................................................................14
List of Abbreviations...................................................................................14
Command Listing........................................................................................14
Quantum ATL M1500
FC310 Router Option
3
4
11
13
1
Advertisement
Table of Contents
Related Manuals for Quantum ATL M1500
Summary of Contents for Quantum ATL M1500
-
Page 1: Table Of Contents
Configuration...4 FC310 Router Option Configuration FC310 Configuration Procedure...4 Upgrading the FC310 Prism Firmware ...7 Commonly Used FC310 Services Software Commands for the ATL M1500 Library FC310 Services Software Commands FC310 Service Software Operation ...13 Command Syntax ...14 List of Abbreviations...14 Command Listing...14... - Page 2 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 6207947-04fN 10...
-
Page 3: Introduction
Operation Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option The ATL M1500 tape library can contain up to two tape drives and up to 21 DLT/SDLT cartridges and 25 LTO cartridge. The ATL M1500 library is controlled by a host computer via a SCSI differential bus using the SCSI-2 medium changer command set. -
Page 4: Key To Successful Configuration Of The Fc310 Option
Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 The FC310 Fibre Channel Option must be configured using the Key to Successful Configuration of the homebred FC310 Prism Router Services software. The key to... - Page 5 Set the SCSI Device Addressing (IDs) for the Library Set the SCSI IDs as shown in Table 1 SCSI ID Settings Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Confirm the SCSI cabling is configured as shown in If necessary, change the cabling to match...
- Page 6 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 Connect a Service PC to the Library Figure 2 FC310 Mounted in the ATL M1500 Locate the RJ45 connector at the bottom of the FC310 Router board in the ATL M1500 library as shown in Connect a 9-pin serial cable (PN 6312122) to the RJ45 connector.
-
Page 7: Upgrading The Fc310 Prism Firmware
Prism Firmware procedure to download the new firmware to the FC310 board: Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Turn on the library or cycle the library power. Upon power-up, the POST output scrolls past the PC screen, as... - Page 8 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 At the prompt type Ready then press <Enter> Type saveconfiguration, prompt. Ready At the prompt, type: Ready firmwarerestart<Enter> From the HyperTerminal menu located at the top of the screen,...
- Page 9 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option At the prompt, type Ready press <Enter> Type saveconfiguration Wait for a new prompt. Ready From the HyperTerminal menu (located at the top of the screen), select Call/Disconnect From the HyperTerminal menu select: File/Properties/Connect To tab/Configure button Set the baud rate to 9600.
- Page 10 Create the FC310 Prism Map for the FC310 Router in the Library A map file is required for the FC310 Router in the ATL M1500 library. It is used by the FC310 to identify the SCSI devices in the library electronically connected to the Fibre Channel port on the board.
-
Page 11: Commonly Used Fc310 Services Software Commands For The Atl M1500 Library
ATL M1500 Library The FC310 Services Software resides on each FC310 Router board. This software configures the router for use in the Quantum ATL M1500 library through a Command Line Interface (CLI) that is compatible with any PC and a terminal emulation program (such as HyperTerminal or ProComm). - Page 12 The user can override the confirmation request by indicating the override value on the command line. Commonly Used FC310 Services Software Commands for the ATL M1500 Library Default Syntax routedisplay routedisplay [fp] routedisplay [online | offline]...
-
Page 13: Fc310 Services Software Commands
Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option The FC310 Services Software is resident on each FC310 Router board, and is used to configure the router for use in the Quantum ATL M1500 library. The software uses a Command Line Interface (CLI) that is usable with any PC and a terminal emulation program such as HyperTerminal or ProComm. -
Page 14: Command Syntax
Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 Command Syntax List of Abbreviations Command Listing Table 3 Most Common FC310 Services Commands Command Description Set the connection mode for the... - Page 15 RouteOnline Set the status of a route to offline. RouteOffline List the currently mapped Fibre RouteDisplay Channel-to-SCSI routes. Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Default hard port 0 = 3 BUSY FC310 Services Software Commands Document 6421018-02, Ver. 2, Rel. 0...
- Page 16 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 Command Description List the available Fibre Channel FcPortList (Immediate) ports and their current status. Specify the SCSI initiator ID to be ScsiInitID used on the specified SCSI port.
- Page 17 C (5-40 degrees Causes the “Fault” LED on the IdentifyFibreBridge FC310 board to blink continuously until disabled. Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Default none FC310 Services Software Commands Document 6421018-02, Ver. 2, Rel. 0...
- Page 18 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 Command Description DispEvent Set the switches which control the filtering performed when displaying events. Switches have the following meanings and settings: (subsystem) switch: mask that controls which subsystem events are displayed.
- Page 19 (Immediate) configuration or the last saved configuration. The new configuration must be saved to take effect. Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Default disabled FC310 Services Software Commands Document 6421018-02, Ver. 2, Rel. 0 September 2002...
- Page 20 Quantum ATL M1500 User’s Guide Addendum - FC310 Router Option Document 6421018-02, Ver. 2, Rel. 0 September 2002 Command Description Save the new configuration. If a SaveConfiguration (Immediate) firmware restart is required to make the change, the user is prompted to confirm the restart.
