Chapter 1 Installing the StackLink
Preparing for the StackLink Installation
Figure 2 Caged Nut
Locations
6
Install caged nuts
in locations marked
by an "X"
If you are installing 3 ATL M2500 library modules
in the rack, do not put caged nuts in these locations
ATL StackLink™ Installation Instructions
FRONT OF RACK
Top mounting tray position
Bottom mounting tray position
BACK OF RACK
Top mounting tray position
Bottom mounting tray position
1U
1U
1U
1U
