Preparing and Inserting Tape Cartridges
3 To cover a 2U gap:
Install the 2U front safety blanking panel (PN 212407) at the front
a
of the rack, securing the panel with two screws (PN YS42011) and
washers (PN YS40404).
Install the two 1U rear safety blanking panels (PN 214218) at the
b
back of the rack, securing each panel with two screws
(PN YS41964) and washers (PN YS41731). Overlap the panels to
cover the 2U gap.
4 To cover a 1U gap:
Install the 1U front safety blanking panel (PN 212406) at the front
a
of the rack, securing the panel with two screws (PN YS42011) and
washers (PN YS40404).
Install a 1U rear safety blanking panel (PN 214218) at the back of
b
the rack, securing the panel with two screws (PN YS41964) and
washers (PN YS41731).
5 To cover a .5U gap:
Install the .5U front panel (PN 215941) at the front of the rack,
a
securing the panel with two screws (PN YS42011) and washers
(PN YS40404).
Install the .5U rear safety blanking panel (PN 214217) at the back
b
of the rack, securing the panel with two screws (PN YS41964) and
washers (PN YS41731).
This section explains how to insert tape cartridges into the ATL M1500
and ATL M2500 libraries. This procedure consists of the following steps:
•
Labeling the tape cartridges
•
Setting the write-protect switch
•
Placing cartridges in the library
ATL StackLink™ Installation Instructions
Chapter 3 Installing the Libraries
Preparing and Inserting Tape Cartridges
3
55
