Chapter 3 Installing the Libraries
Preparing and Inserting Tape Cartridges
Figure 40 Setting the
Write-Protect Switch
(DLT and SDLT
Cartridges)
Figure 41 Setting the
Write-Protect Switch
(LTO Cartridges)
58
Orange tab
Write-protect switch
Setting the Write-Protect Switch (LTO Cartridges)
To write-protect an LTO cartridge, move the write-protect switch to the
right (see figure 41).
To write-enable an LTO cartridge, move the write-protect switch to the
left.
Write-protect switch
Slide left
Write-
enabled
Write-
protected
Slide right
ATL StackLink™ Installation Instructions
3
