ATL M1500 Universal
Rack Mount Kit
Part No. Description
213467 Shelf clamp
213468 Insert (9 sq)
213469 Insert (7 sq)
213471 Insert (M6)
213472 Insert (M5 or 12-24UNC)
213473 Insert (10-32UNF)
213474 Insert (1/4" dia)
213476 Universal shelf, right
213477 Universal shelf, left
213478 Shelf extender #1
213479 Shelf extender #2
YS40403 Plain washer M5
YS40403 Plain washer M5
YS41720 Button head socket screw 10-24 UNC x 0.5 ins
YS41998 Nut, M5 full
YS42008 M6 cage nut
YS42011 Button head socket screw M6 x 12
YS42038 Countersink hex socket screw M4 X 10 LG
YS42042 Button head socket screw M5 x 12
YS42043 Button head socket screw 10-32 UNC x 0.5 ins
YS42044 M5 spire nut
ATL StackLink™ Installation Instructions
Chapter 2 Installing the Rack Mount Shelves
Installing the Shelves
Qty.
4
8
8
8
8
8
8
1
1
1
1
4
2
2
4
2
2
4
2
2
2
23
