Chapter 3 Installing the Libraries
Preparing and Inserting Tape Cartridges
Figure 45 Release
Latch
Figure 46 Removing
the Level 1 Left
Magazine
62
Release latch
While holding the release latch, pull the level 1 left magazine
e
forward and out of the library (see
ATL StackLink™ Installation Instructions
figure
46).
